With its classy looks, exacting attention to detail and practical integration, the Alpenchallenge AL could only be a BMC. Its sporty, endurance-inspired, smooth welded, powder coated Premium Aluminium frame is paired with a carbon fork with fender and cargo mounts, and internal hub dynamo routing. An adventurous component specification has a 12-speed SRAM Eagle AXS drivetrain with ultra-wide gear ratios, TEKTRO HD-EU818 disc brakes, SR500 wheelset, and Vittoria Randonneur – 37mm tires.

Technical Overview

Frameset

Cockpit

Stem:
BMC MSM 01

Handlebar:
BMC LSB 03

Seat

Seatpost:
BMC LSP 02

Saddle:
Selle Royal Vivo

Brakes

Brake Levers / Calipers:
TEKTRO HD-EU818

Rotors:
TEKTRO TR180-25 / TR180-25

Rotor Size (F/R):
180 / 180mm

Wheels

Rims:
SR500

Hubs (F/R):
CL-712 | RXC-142S

Tires:
Vittoria Randonneur | 37mm

Additional Information

Tire Clearance:
42mm

Weight without Pedals:
11.48 kg | Size M

ASTM Classification:
Level 2

System Weight Limit:
120kg

General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)

Size	S	M	L	XL
Rider Height	<168	168-180	178-190	>190
Reach	400	415	425	440
Stack	560	590	620	650
Bar Width	600	600	600	600
BB Drop	67	67	67	67
Crank Length	170	170	175	175
Fork Length	408	408	408	408
Fork Rake	45	45	45	45
Front Center	631	657	677	703
Head Tube	133	165	197	229
Head Tube Angle	70	70	70	70
Rear Center	440	440	440	440
Seat Angle	74	74	74	74
Seat Tube	480	510	540	555
Seatpost Length	350	350	350	350
Seatpost Offset	15	15	15	15
Standover Height	760	790	819	838
Stem Angle	-5	-5	-5	-5
Stem Length	80	80	90	90
Top Tube	560	584	603	626
Trail	75	75	75	75
Wheelbase	1062	1088	1109	1135
