Technical Overview
Frameset
Frame:
Alpenchallenge Premium Aluminium | Smoothwelded | Powder Coat Finish | Internal Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Alpenchallenge Premium Aluminium | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Stem:
BMC RSM 01
Handlebar:
BMC LSB 03
Seat
Seatpost:
BMC LSP 02
Saddle:
Selle Royal Vivo
Drivetrain
Crankset:
FSA Vero Pro
Chainrings:
40T
Cassette:
SHIMANO Deore (CS-M6100)
Cassette Size:
10-51T
Chain:
SHIMANO Deore CN-M6100
Rear Derailleur:
SHIMANO Deore (RD-M6100)
Shifters:
SHIMANO Deore (SL-M6100) | Rapidfire Plus
Gears:
1 x 12
Bottom Bracket:
BSA Threaded Bottom Bracket
Brakes
Brake Levers / Calipers:
TEKTRO HD-R280
Rotors:
TEKTRO TR180-35 / TR180-35
Rotor Size (F/R):
180 / 180mm
Wheels
Rims:
PFR300
Hubs (F/R):
CL-712 | CL-142M
Tires:
Vittoria Randonneur | 37mm
Tubeless Information:
Non-Tubeless Rims | Non-Tubeless Clincher Tire
Additional Information
Tire Clearance:
42mm measured tire
ASTM Classification:
Level 2
System Weight Limit:
120kg
