Technical Overview
Frameset
Frame:
Roadmachine AMP Premium Carbon with Tuned Compliance Concept Endurance | Integrated removable Internal Battery | Internal Cable Routing | Integrated Seatpost Clamp | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Roadmachine AMP Premium Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle | 50mm offset (Size 47-51) 45mm offset (Size 54-61)
E-System
Drive Unit:
Mahle X20
Battery Pack:
Mahle iX350 | Optional 172 Wh Range Extender | 350 Wh
Display:
Mahle Head Unit
Drive Unit Control:
Mahle Head Unit
Charger:
Mahle X20 Active Charger
Cockpit
Stem:
BMC RSM 01
Handlebar:
BMC RAB 02 | Ergo Top Shape | Compact Bend
Seat
Seatpost:
Roadmachine AMP Premium Carbon D-Shaped Seatpost | 15mm Offset
Saddle:
Fizik Taiga
Brakes
Brake Levers / Calipers:
SHIMANO 105 (BR-R7070)
Rotors:
SHIMANO SM-RT70
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
XRD-522 | Tubeless Ready | 25 mm
Hubs (F/R):
XRD-522 | Ebikemotion
Tires:
Vittoria Rubino Pro | 30mm
Additional Information
Tire Clearance:
33mm
ASTM Classification:
Level 2
System Weight Limit:
120kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
| Reach | 374 | 382 | 386 | 390 | 394 | 398 |
| Stack | 516 | 541 | 562 | 586 | 610 | 644 |
| Bar Drop | 125 | 125 | 125 | 125 | 125 | 125 |
| Bar Reach | 70 | 70 | 70 | 70 | 70 | 70 |
| Bar Width | 400 | 420 | 420 | 420 | 420 | 440 |
| BB Drop | 71 | 71 | 71 | 71 | 71 | 71 |
| Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Fork Length | 375 | 375 | 375 | 375 | 375 | 375 |
| Fork Rake | 50 | 50 | 45 | 45 | 45 | 45 |
| Front Center | 583 | 599 | 597 | 609 | 621 | 635 |
| Head Tube | 112 | 139 | 156 | 181 | 206 | 242 |
| Head Tube Angle | 71.2 | 71.2 | 72 | 72 | 72 | 72 |
| Rear Center | 410 | 410 | 410 | 410 | 410 | 410 |
| Seat Angle | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 |
| Seat Tube | 420 | 457 | 500 | 522 | 539 | 573 |
| Seatpost Length | 330 | 380 | 380 | 380 | 380 | 430 |
| Seatpost Offset | 15 | 15 | 15 | 15 | 15 | 15 |
| Standover Height | 719 | 750 | 782 | 805 | 825 | 859 |
| Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
| Stem Length | 90 | 90 | 100 | 110 | 110 | 120 |
| Top Tube | 522 | 532 | 546 | 556 | 568 | 583 |
| Trail | 63 | 63 | 63 | 63 | 63 | 63 |
| Wheelbase | 982 | 999 | 997 | 1008 | 1020 | 1035 |
