Technical Overview
Frameset
Frame:
Roadmachine X Premium Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Roadmachine X Premium Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Stem:
ICS MTT x Redshift Suspension Stem | Integrated Cockpit System Technology
Handlebar:
BMC RAB 02 | Ergo Top Shape | Compact Bend
Seat
Seatpost:
Roadmachine X Premium Carbon D-Shaped Seatpost
Saddle:
Fizik Terra Argo X3
Drivetrain
Crankset:
SRAM Force 1
Chainrings:
SRAM Apexrings
Cassette:
SRAM Force AXS XPLR (XG-1271)
Cassette Size:
10-44T
Chain:
SRAM Apex
Rear Derailleur:
SRAM Force XPLR eTap AXS
Shifters:
SRAM Force eTap AXS HRD
Gears:
1 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SRAM Force eTap AXS HRD
Rotors:
SRAM Centerline X Rotors
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
CRD-321 Carbon | Tubeless Ready | 35mm
Hubs (F/R):
CRD-321
Tires:
WTB Expanse | 32mm
Additional Information
Tire Clearance:
33mm measured tire
Weight without Pedals:
8.15 kg | Size 54
ASTM Classification:
Level 2
System Weight Limit:
110kg
