Name: Teammachine SLR 01 MOD
Brand: BMC
SKU: 301504006227
Availability: OutOfStock

Teammachine SLR 01 MOD | BMC | frames | Road, Road | Racing

Color: Race Grey
Model Year: 2019

BMC Archive Product

[{"id":41912507465807,"title":"54","option1":"54","option2":null,"option3":null,"sku":"301504006227","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 01 MOD - 54","public_title":"54","options":["54"],"price":0,"weight":12000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027825374","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41912507826255,"title":"56","option1":"56","option2":null,"option3":null,"sku":"301504006232","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Teammachine SLR 01 MOD - 56","public_title":"56","options":["56"],"price":0,"weight":12000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027825381","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Technical Overview

Frameset

Frame:
Teammachine SLR01 - PF86 bottom bracket | 01 Premium Carbon - ACE Technology - TCC Race

Cockpit

Handlebar:
BMC RCB01 Carbon | ergo top shape | compact ben

Stem:
BMC RSM01 | w/ computer and camera mount

Seatpost:
Teammachine SLR01 "D" Premium Carbon | 15mm of

Saddle:
Fizik Antares R1 Carbon

Additional Information

General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)

Size	47	51	54	56	58	61
Rider Height	<166	166-174	172-180	178-186	184-192
Reach	367	377	386	392	401	409
Stack	506	530	550	565	584	608
Bar Drop	123	123	123	123	123	123
Bar Reach	77	77	77	77	77	77
Bar Width	400	420	420	420	440	440
BB Drop	69	69	69	69	69	69
Crank Length	170	170	172.5	172.5	172.5	175
Fork Length	365	365	365	365	365	365
Fork Rake	41.6	41.6	41.6	41.6	41.6	41.6
Front Center	570	575	587	596	611	627
Head Tube	113	133	153	168	188	213
Head Tube Angle	70.5	72	72.5	72.5	72.5	72.5
Rear Center	410	410	410	410	410	410
Seat Angle	73.5	73.5	73.5	73.5	73.5	73.5
Seat Tube	423	468	513	534	554	584
Seatpost Length	300	300	330	330	330	330
Seatpost Offset	15	15	15	15	15	15
Stem Angle	+/- 8	+/- 8	+/- 8	+/- 8	+/- 8	+/- 8
Stem Length	90	100	110	120	120	120
Top Tube	517	535	550	560	575	590
Trail	76	66	63	63	63	63
Wheelbase	970	975	986	996	1012	1027
